Single-phase induction domestic water pump - CR71M2C .75 CAM100

The growing population of apartment dwellers and the significant increase in water consumption have made adequate water supply a serious challenge, especially in large cities. Therefore, a domestic water pump is an essential piece of equipment for daily life.

Two main factors are considered in the design and manufacture of a domestic water pump:

1- Flow rate (Q): The volume of fluid the pump can deliver per unit time. The pump's flow rate depends on the number of service units and water outlets in the system.

2- Head (H): The maximum height the pump can overcome to transport the fluid.

Motogen jet pump (CAM100) delivers a maximum head of 45 meters and a flow rate of 3 cubic meters per hour in self-priming mode, suitable for four-story single-unit buildings.

Motogen centrifugal pump (CM100) provides a maximum head of 32 meters and a maximum flow rate of 5 cubic meters per hour, making it suitable for one- to three-story single-unit buildings.

Motogen pumps are equipped with a thermo-guard to protect against motor overheating and have an IP44 protection rating, operating at a nominal voltage of 220 volts and a speed of 2800 rpm.

specifications

Electro motor with exact frame size and dimensions, suitable for various applications.
