Single-speed single-phase induction cooler electro pump

Motogen's evaporative cooler water pump is a key cooler component that circulates water within the system. Driven by an electric motor, it pressurizes and moves water from the cooler's tank to other parts. These pumps are easily removed and replaced when needed, so regular inspection and maintenance ensure quick and high-quality replacements.

Motogen's cooler water pumps are domestically produced with high-quality metal construction, featuring an iron body and stainless steel shaft. They operate on single-phase 220-230 V mains power at 2200-3000 rpm, delivering 6 to 12 m at one-meter head. Equipped with plastic impellers, they are also suitable for small units. The mechanical system uses bushings for shaft rotation, and windings may be aluminum or copper depending on application.

Motogen manufactures cooler water pumps with the following technical specifications:

- Strong suction capability.

- Easy-installation hood for pump protection against water.

- Quiet operation.

- IP23 protection rating.

- Suitable for continuous operation.

- IC01 ventilation method with rotor vanes.

- Thermal class B.

- 50 Hz operating frequency.

- 220 V nominal voltage.

Additionally, these pumps have a compact design and corrosion- and leak-resistant materials, capable of high-pressure water transfer for cooling systems, saving energy and offering efficient performance.

specifications

Electro motor with exact frame size and dimensions, suitable for various applications.
