3-phase 70KVA salient pole AC generator

Given the need for electricity in urban and industrial applications, electricity generation must be a societal goal. A generator is a crucial component in electric power production.

As Motogen operates in both motor and generator sectors, it aims to research and eventually mass-produce generators, starting with prototypes.

A generator converts mechanical energy into electrical energy and comprises power generation and excitation sections.

Generators are generally classified as AC or DC and can have separate or self-excitation. As this is an AC self-excited generator, its main components are:

- Main stator: Produces AC voltage and supplies output current.

- Main rotor: Contains laminated salient poles and induces voltage from the excitation winding to the stator winding.

- Excitation stator: Generates the magnetic field for rotor excitation.

- Excitation rotor: Produces DC voltage and delivers it to the main rotor via rectifier.

- Automatic Voltage Regulator (AVR): Controls voltage and current loop between power and excitation sections.

- Rectifier: Converts three-phase excitation voltage to DC for the excitation winding.

In operation, DC from the rotor rectifier excites the main rotor winding, creating a magnetic field. As the rotor spins, the stator windings cut this field, inducing three-phase AC. Two stator phases feed the AVR, which adjusts DC to the excitation stator to maintain constant output voltage across load conditions.

specifications

Electro motor with exact frame size and dimensions, suitable for various applications.
