Flame Detector with Line of Sight model NFDL-50260

Информация о продукте

This model is a Line of sight flame detector that is installed directly on the furnace. The light of flame by the optical lens is focused on the sensor. The sensor converts the light into electrical signals. The flame signal is analyzed by the central processor and monitored in the output. Overview This model is a Line of sight flame detector that is installed directly on the furnace. The light of flame by the optical lens is focused on the sensor. The sensor converts the light into electrical signals. The flame signal is analyzed by the central processor and monitored in the output. Key Features For ambient temperatures from -40°c up to +85°c; Two parallel channels to increase the safety of the device; Flame flicker frequency measurement; Usable for all burners with different fuels. Applications Power stations; Petrochemical industry; Steel industry; Cement factory; Refineries; Steam generators; Waste incinerators; Heating systems. Standards EMC Standards: IEC 61000-4-2 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-11 IEC 61000-4-3 IEC 61000-4-6 Vibration Standard Temperature Standard IP66 Standard
